The TH112

Compact design for tour sound or cinema

th112 header image


The TH112 is a very compact design which combines high efficiency with solid output down to 27 Hz

The TH112 can be used individually in installed loudspeaker systems or used in multiples for tour sound or cinema applications.

Incredible deep bass from a single 12!


  • operating
    frequency range
    33 Hz - 200 Hz -3dB
    27 Hz - 260 Hz -10 dB
  • continuous output
    126 dB SPL
  • peak output
    132 dB SPL
  • sensitivity
    100 dB SPL (2.83 Volts into rated Z, at 1 meter), measured in half space
  • driver complement
    one 12" Long Excursion Woofer
  • dimensions
    38 x 18 x 30.2 inches
  • weight
    142 lbs
  • Rated Impedance
    8 Ohms
  • Power Rating
    400 W continuous, 800 W program
