The SM80F

The SM80F performs like no other loudspeaker its size. Combining synergy and tapped horn technology in one relatively small package, this loudspeaker hardly needs sub-woofers to boast impressive low end while providing clean and clear audio across the rest of the frequency spectrum.

A true full range speaker

Specifications

  • coverage Pattern
    80° Conical
  • operating
    frequency range
    45Hz-17kHz +/- 3dB
    39Hz-23kHz - 10dB
  • continuous output
    Mid/High 128 dB SPL
    Low 135 dB SPL
  • peak output
    Mid/High 134 dB SPL
    Low 141 dB SPL
  • sensitivity
    Mid/High 102 dB SPL
    Low 106 dB SPL
  • driver complement
    1 x 12" coaxial
    2 x 15" woofers
  • dimensions
    45 x 28 x 28 inches
  • weight
    215 lbs
  • Rated Impedance
    Mid/High 8 Ohms
    Low 2 Ohms
  • Power Rating
    Mid/High
    400 Watts Cont.
    1600 Watts Peak
    Low
    3400 Watts Cont.
    13,600 Watts Peak
