The DTS10

dts10 header image

DTS10

The DTS10 is one of our "monster" category of Danley subwoofers

It is the reference standard high definition cinema subwoofer with an unheard of output down to 10 Hz—at least twice the power of the renown DTS20. The DTS10 was originally produced as an industry first "do-it-yourself" subwoofer kit. But now, the new and improved DTS10 is a regular member of our product line. It makes an outstanding home theatre solution and is guaranteed to make any home theatre enthusiast drool.

High-def sub!

Specifications

  • coverage Pattern
    NA
  • operating
    frequency range
    15 Hz- 70 Hz - 3dB
    12 Hz -10dB
  • continuous output
    127 dB SPL
  • peak output
    133 dB SPL
  • sensitivity
    100 dBSPL (2.83 Volts into rated Z, at 1 meter) measured in half space
  • driver complement
    two 12" long excursion woofers
  • dimensions
    59.5 x 44 x 16 inches
  • weight
    285 lbs
  • Rated Impedance
    4 Ohms
  • Power Rating
    1000 W continuous, 2000 W program
