The CS30

Over 120 dB Spl at 33 Hz!

cs30 header image

CS30

The CS30 combines high sensitivity with very low frequency cutoff in a sub-compact package

The CS30 is available in both touring and install models for easy installation or portability.

Get the Specifications

Download Spec Sheet
Download Drawings (ZIP Files)

The worlds smallest commercial output subwoofer

Specifications

  • operating
    frequency range
    33 Hz- 67 Hz - 3dB
    27 Hz- 150 Hz - 10dB
  • continuous output
    121 dBSPL
  • peak output
    127 dB SPL
  • sensitivity
    95 dB SPL (2.83 Volts into rated Z, at 1 meter) measured in half space
  • driver complement
    one 12" woofer
  • dimensions
    24 x 15 x 24 inches
  • weight
    83 lbs
  • Rated Impedance
    8 Ohms
  • Power Rating
    400 W continuous, 800 W program
